Product Details
Management features
Switch type
Managed
Switch layer
L2/L3
Quality of Service (QoS) support
Yes
Web-based management
Yes
ARP inspection
Yes
MIB support
Y
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity
24
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
SFP module slots quantity
2
Network
Networking standards
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3at, IEEE 802.3az, IEEE 802.3x
Port mirroring
Yes
Full duplex
Yes
Flow control support
Yes
Link aggregation
Yes
Broadcast storm control
Yes
Rate limiting
Yes
Spanning tree protocol
Yes
Auto-negotiation
Yes
VLAN support
Yes
Virtual LAN features
Port-based VLAN, Private VLAN, Voice VLAN
Number of VLANs
256
Data transmission
Switching capacity
52 Gbit/s
MAC address table
16000 entries
Store-and-forward
Yes
Jumbo frames support
Yes
Packet buffer memory
1.5 MB
Security
DHCP features
DHCP client
Access Control List (ACL)
Yes
IGMP snooping
Yes
Loop protection
Yes
Multicast features
Multicast support
Yes
Design
Rack mounting
Yes
Form factor
1U
Product colour
Black
LED indicators
Yes
Number of fans
2 fan(s)
Performance
Built-in processor
Yes
Processor frequency
800 MHz
Memory type
RAM
Internal memory
512 MB
Flash memory
64 MB
Noise level
26.1 dB
Power
Power source
PoE
Power over Ethernet (PoE)
Power over Ethernet (PoE)
Yes
Power over Ethernet plus (PoE+) ports quantity
24
Total Power over Ethernet (PoE) budget
190 W
Other features
Warranty period
3 year(s)
Operational conditions
Operating temperature (T-T)
0 - 50 °C
Storage temperature (T-T)
-20 - 70 °C
Operating relative humidity (H-H)
0 - 95%
Storage relative humidity (H-H)
0 - 95%
Operating altitude
0 - 3000 m
Weight & dimensions
Width
440 mm
Depth
253 mm
Height
43 mm
Weight
3.53 kg
Packaging content
Quick start guide
Yes
User guide
Yes
Manual
Yes
Technical details
Shipping (inner) case height
38 cm
Shipping (inner) case width
56.7 cm
Shipping (inner) case length
24.1 cm
Shipping (inner) case net weight
10.9 kg
Products per shipping (inner) case
2 pc(s)
Information
| Part Number: | GS324TP-200EUS |
