Product Details
Introduction
Enjoy 8 streams of WiFi 6 for 4X more device capacity and more bandwidth for more streaming, gaming, and browsing for the whole family. With up to 1.2 + 4.8Gbps + 600Mbps of ultra-fast WiFi speeds, connect more devices than ever before reliably and simultaneously.
WAN connection
Ethernet WAN
Y
DSL WAN
N
SIM card slot
N
3G/4G USB modem compatibility
N
WAN connection type
RJ-45
Wireless LAN features
Wi-Fi band
Tri-band (2.4 GHz / 5 GHz / 5 GHz)
Top Wi-Fi standard
Wi-Fi 6 (802.11ax)
WLAN data transfer rate (max)
6600 Mbit/s
Wi-Fi standards
802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac),Wi-Fi 6 (802.11ax)
WLAN data transfer rate (first band)
1200 Mbit/s
WLAN data transfer rate (second band)
4800 Mbit/s
WLAN data transfer rate (third band)
600 Mbit/s
Modulation
256-QAM,1024-QAM
Network
Ethernet LAN
Y
Ethernet LAN interface type
Gigabit Ethernet
Ethernet LAN data rates
10,100,1000 Mbit/s
Networking standards
IEEE 802.11a,IEEE 802.11ac,IEEE 802.11ax,IEEE 802.11b,IEEE 802.11g,IEEE 802.11i,IEEE 802.11n
USB sharing
Y
Mobile network
3G
N
4G
N
5G
N
Ports & interfaces
Ethernet LAN (RJ-45) ports
4
USB port
Y
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
1
Memory card slot(s)
N
DC-in jack
Y
Management features
Web-based management
Y
MU-MIMO technology
Y
Security
Security algorithms
128-bit AES
Design
Product colour
Black
Indication light
Y
On/off switch
Y
Product type
Tabletop router
Antenna
Antenna type
External
Features
Built-in processor
Y
Processor frequency
1500 MHz
Processor cores
4
Works with Amazon Alexa
Y
Works with the Google Assistant
Y
Power
Power source type
DC
System requirements
Browser supported
Microsoft® Internet Explorer® 11 or higher, Microsoft Edge, Google ChromeT 55 or higher, Firefox® 45 or higher, Safari® 10 or higher
Windows operating systems supported
Windows 10,Windows 2000,Windows 7,Windows 8,Windows Vista,Windows XP
Linux operating systems supported
Y
Mac operating systems supported
Y
Weight & dimensions
Width
347 mm
Depth
208 mm
Height
165 mm
Weight
1.17 kg
Packaging data
Cables included
LAN (RJ-45)
AC adapter included
Y
Quick start guide
Y
Package width
251 mm
Package depth
341 mm
Package height
147 mm
Package weight
2.13 kg
Information
| Part Number: | RAX70-100EUS |
