NEWLAND Companion Scanner - Bs80 Piranha Ii 2d Cmos Blueth Scanner Reads 1/2d Barcodes

NEWLAND Companion Scanner - Bs80 Piranha Ii 2d Cmos Blueth Scanner Reads 1/2d Barcodes

£134.37 (incl. VAT)

Qty:

Add to basket

Part Number:	NLS-BS8080-2D
	In Stock
	Delivery: 1 - 2 days

Product Details

Introduction

Superior Reading Performance

The BS80 Piranha II is offered in 2 versions, containing a 1D or a 1D+2D barcode scanning engine. Both of these engines read virtually any barcode from paper or screen. The 2D device has been equipped with a laser aimer with a red cross to make barcode reading easier and faster.

Easy Bluetooth Pairing

With Bluetooth 4.0 wireless technology, the BS80 Piranha II enables effortless pairing to any Android, iOS, or Windows device, making it simple and convenient for users to transmit data.

Seamless Barcode Capture and Storage

Offering versatile barcode scanning capabilities, the BS80 Piranha II enables fast real-time scanning with seamless data transfer to the host via Bluetooth. However, users can also take advantage of the 1MB memory when operating in batch collection mode, which can store thousands of barcodes offline for subsequent download via Bluetooth or cable.

Edits On the Go

The BS80 Piranha II boasts not only a reliable scan button but also two extra buttons for convenient data editing. For data collection mode, the Delete button allows users to quickly rectify scanning errors by deleting the last scanned barcode. Meanwhile, the Function button serves as a virtual keyboard recall feature, enabling manual data input on a wide range of host devices, including iOS products. This makes the BS80 Piranha II an ideal companion for all your data collection needs.

Versatile Charging & Communication

The BS80 Piranha II features a fast and reliable USB-C port that can be used both for charging and establishing a connection to a host to download data or access the EasySet configuration software. In addition, the device also supports the use of pogo pins to charge via the cradle.

Multi-Device Charging

The BS80 Piranha II offers an optional two-bay charging solution that can be easily linked together to create a multi-charging station. With optimized charging capabilities, users can daisy-chain up to five cradles, allowing them to charge up to ten scanners simultaneously using a single power supply.

Scanning

Type Handheld bar code reader

Scanner type 1D/2D

Sensor type CMOS

Linear (1D) barcodes supported China Post, Codabar, Code 128, Code 39, Code 93, EAN-13, EAN-8, GS1 DataBar, GS1-128 (UCC/EAN-128), ISBN, ISSN, Interleaved 2 of 5, MSI, PDF417, POSTNET, Plessey, UPC-A, UPC-E

2D (matrix & stacked) barcodes supported Aztec Code, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR Code

Optical sensor resolution (W x H) 1280 x 800 pixels

Pitch reading angle -60 - 60°

Ports & interfaces

Connectivity technology Wired & Wireless

Standard interfaces Bluetooth, USB

Wireless range 50 m

Bluetooth version 4.0

Bluetooth Low Energy (BLE) Yes

Operating frequency 2400 - 2500 MHz

Performance

International Protection (IP) code IP42

Protection features Drop proof

LED indicators Yes

Buzzer Yes

Internal memory 1 MB

Print contrast 20%

Product colour Black, Orange

Programming function Yes

Vibration function Yes

Certification TELEC, IEC 62471, IEC60825

Power

Power source type Battery

Battery technology Lithium-Ion (Li-Ion)

Battery type Built-in battery

Battery capacity 900 mAh

Battery voltage 3.7 V

Battery life 5 h

Power consumption 0.28 mA

Weight & dimensions

Width 46 mm

Depth 88 mm

Height 24.5 mm

Weight 63 g

Operational conditions

Operating temperature (T-T) -20 - 50 °C

Storage temperature (T-T) -40 - 70 °C

Operating relative humidity (H-H) 5 - 95%

Technical details

Sustainability compliance Yes

Compliance certificates CE, Federal Communications Commission (FCC), RoHS

Information

Part Number:

NLS-BS8080-2D
