Product Details
Introduction
Our S Line monitor delivers business efficiency. Features like Flicker-free and LowBlue mode make work easy on the eyes and increase your productivity.
Display
sRGB coverage (typical)
99%
Display diagonal
61 cm (24")
HD type
Full HD
Display technology
LCD
Touchscreen
No
Display brightness (typical)
300 cd/m²
Response time
4 ms
Screen shape
Flat
Maximum refresh rate
75 Hz
Viewing angle, horizontal
178°
Viewing angle, vertical
178°
Pixel density
93 ppi
Viewable size, horizontal
52.7 cm
Viewable size, vertical
29.6 cm
Digital horizontal frequency
30 - 85 kHz
Digital vertical frequency
48 - 75 Hz
Display diagonal (metric)
60.5 cm
Haze rate
25%
Colour depth
8 bit
RGB colour space
sRGB
NTSC coverage (typical)
80%
Display resolution
1920 x 1080 pixels
Native aspect ratio
16:9
Panel type
VA
Backlight type
W-LED
Anti-glare screen
Y
Contrast ratio (typical)
3000:1
Contrast ratio (dynamic)
50000000:1
Dynamic contrast ratio marketing name
SmartContrast
Display number of colours
16.7 million colours
Pixel pitch
0.2745 x 0.2745 mm
DDC/CI
Y
Surface hardness
3H
Display sRGB
Y
LED backlight
Yes
Horizontal scan range
30 - 85 kHz
Vertical scan range
48 - 75 Hz
Colour gamut
80%
Display panel size
23.8 inch / 60.5 cm
Performance
Low Blue Light technology
Yes
Compatible operating systems
Windows 11 / 10 / 8.1 / 8 / 7
Mac OS X
VESA Adaptive Sync support
Y
Component video sync
Separate sync, Sync-on-green (SOG)
Flicker-free technology
Y
Multimedia
Built-in camera
No
Number of speakers
2
RMS rated power
2 W
Built-in speaker(s)
Y
Design
Market positioning
Business
Heavy metals free
Hg (mercury)
Product colour
Black
Front bezel colour
Black
Feet colour
Black
Ports & interfaces
Built-in USB hub
Yes
USB hub version
3.2 Gen 1 (3.1 Gen 1)
USB upstream port type
USB Type-B
Number of upstream ports
1
Number of USB Type-B upstream ports quantity
1
USB Type-A downstream ports quantity
4
USB Power Delivery
Yes
VGA (D-Sub) ports quantity
1
DVI port
Yes
DVI-D ports quantity
1
HDMI
Yes
HDMI ports quantity
1
HDMI version
1.4
DisplayPorts quantity
1
DisplayPort version
1.2
HDCP version
1.4
Audio output
Y
PC Audio in
Y
HDCP
Y
Ergonomics
Height adjustment
Yes
Height adjustment
13 cm
Pivot
Yes
Pivot angle
-90 - 90°
Swivelling
Yes
Swivel angle range
-180 - 180°
Tiltable
Yes
Tilt angle range
-5 - 25°
VESA mounting
Y
Panel mounting interface
100 x 100 mm
Cable lock slot
Y
Cable lock slot type
Kensington
On Screen Display (OSD) languages
Simplified Chinese, Traditional Chinese, Czech, German, Dutch, English, Spanish, Finnish, French, Greek, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Swedish, Turkish, Ukrainian
Plug and Play
Y
LED indicators
Operation, Stand-by
On Screen Display (OSD)
Yes
Power
Energy consumption (SDR) per 1000 hours
21 kWh
Power consumption (typical)
15 W
Power consumption (standby)
0.4 W
Power consumption (off)
0.3 W
Power consumption (PowerSave)
12 W
AC input voltage
100 - 240 V
Energy efficiency class (SDR)
E
AC input frequency
50/60 Hz
Power supply type
Internal
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-20 - 60 °C
Operating relative humidity (H-H)
20 - 80%
Operating altitude
0 - 3658 m
Non-operating altitude
3658 - 12192 m
Weight & dimensions
Width (with stand)
539 mm
Depth (with stand)
205 mm
Height (with stand)
484 mm
Weight (with stand)
4.85 kg
Width (without stand)
539 mm
Depth (without stand)
55 mm
Height (without stand)
324 mm
Weight (without stand)
3.09 kg
Packaging data
Package width
730 mm
Package depth
139 mm
Package height
420 mm
Package weight
7.15 kg
Sustainability
Sustainability compliance
Yes
Sustainability certificates
ENERGY STAR, TCO, RoHS
Doesn't contain
Mercury, PVC/BFR
European Product Registry for Energy Labelling (EPREL) code
1291734
Recycling data
Post-consumer recycled plastic
85%
Other features
Recyclable packaging material
100%
Mean time between failures (MTBF)
70000 h
Exterior finish type
Textured
Picture enhancement
SmartImage
Regulatory Approvals
CB; CE Mark; CU-EAC; EAEU RoHS; FCC Class B; ICES-003; SEMKO; TUV Ergo; TUV/GS
EasyRead mode
Y
LowBlue mode
Y
Monitor sync input signal
Separate Sync; Sync on Green
User controls
SmartImage/Back; Brightness/UP; Input/Down; Menu/OK; Power On/Off
Packaging content
Stand included
Y
Cables included
HDMI, DisplayPort, AC
Manual
Y
Bundled software
SmartControl
Technical details
Compliance certificates
RoHS
Information
| Part Number: | 242S9JML/00 |
