Product Details
Storage
Supported storage drive interfaces
Serial ATA II, Serial ATA III
Storage drive sizes supported
2.5,3.5"
RAID support
Y
RAID levels
0, 1, 5, 6, 10, JBOD
Online RAID migration
Y
Online RAID expansion
Y
RAID rebuild
Y
Hot-swap drive bays
Y
Supported file systems
FAT32, HFS+, NTFS, exFAT, ext3, ext4
Storage drives installed
N
Number of storage drives supported
4
Installed storage drive type
N
Supported storage drive types
HDD & SSD
Disk roaming
Y
Storage drive capacity
0 GB
Total installed storage capacity
0 TB
Processor
Processor manufacturer
Intel
Processor family
Intel® Celeron®
Processor boost frequency
2.9 GHz
Processor cores
4
Processor threads
4
On-board graphics card model
Intel® UHD Graphics
Processor model
N5095
CPU configuration (max)
1
Processor frequency
2 GHz
Memory
Maximum RAM supported
8 GB
Internal memory
8 GB
Flash memory
4000 MB
Internal memory type
DDR4
Memory slots
2
Memory form factor
SO-DIMM
Network
Ethernet LAN
Y
Ethernet LAN data rates
10,100,1000,2500 Mbit/s
DHCP client
Y
DHCP server
Y
Jumbo frames support
Y
iSCSI support
Y
Wake-on-LAN ready
Y
Dynamic DNS (DDNS)
Y
Copper ethernet cabling technology
10BASE-T, 100BASE-TX, 1000BASE-T, 2500BASE-T
Ports & interfaces
USB port
Y
USB 2.0 ports quantity
2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
2
HDMI ports quantity
1
HDMI version
1.4b
Ethernet LAN (RJ-45) ports
2
Concurrent connections
1500
PCI Express x2 (Gen 3.x) slots
1
Design
Chassis type
Rack (1U)
Cooling type
Active
Product colour
Black
Number of fans
2 fan(s)
Fan diameter
4 cm
LED indicators
HDD, LAN, Power, Status
Performance
Type
NAS
Device class
Small & Medium Business
Backup function
Y
Backup features
Cloud, iSCSI LUN
Buzzer
Y
Multilingual support
Y
Snapshot
Y
Security algorithms
256-bit AES, FIPS 140-2, HTTPS, SSH
Access Control List (ACL)
Y
Reset button
Y
On/off switch
Y
Built-in FTP server
Y
Browser supported
Apple Safari, Google Chrome, Microsoft Edge, Mozilla Firefox
System log
Y
Hot spare
Y
Disk scan
Y
S.M.A.R.T. support
Y
Share folder
CIFS/SMB
Management protocols
SNMP V2, V3
Software
Operating system installed
QNAP Turbo System
Operating system version
5.0.0
Windows operating systems supported
Windows 10, Windows 11, Windows 7, Windows 8
Linux operating systems supported
Y
Mac operating systems supported
Y
Server operating systems supported
Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Other operating systems supported
Solaris 10
Power
Power supply location
Built-in
Power supply unit (PSU) capacity
250 W
Number of power supply units
1
AC input voltage
100 - 240 V
AC input frequency
50 - 60 Hz
Fan voltage
12 V
Power consumption (typical)
36.81 W
Power consumption (sleep)
22.285 W
Weight & dimensions
Width
482.6 mm
Depth
483.9 mm
Height
43.3 mm
Weight
6.6 kg
Package weight
8.54 kg
Package width
667 mm
Package depth
612 mm
Package height
160 mm
Technical details
Harmonized System (HS) code
84714100
Packaging content
Cables included
AC, LAN (RJ-45)
Power cables quantity
1
Number of screws
84
Package type
Box
Quick start guide
Yes
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Operating relative humidity (H-H)
5 - 95%
Storage temperature (T-T)
-20 - 70 °C
Other features
Warranty period
3 year(s)
Processor special features
Enhanced Intel SpeedStep Technology
Yes
Idle States
Yes
Intel 64
Yes
Intel Trusted Execution Technology
No
Intel Virtualization Technology (VT-x)
Yes
Intel Virtualization Technology for Directed I/O (VT-d)
Yes
Intel VT-x with Extended Page Tables (EPT)
Yes
Information
| Part Number: | TS-464U-8G |
