Product Details
Scanning
Type
Handheld bar code reader
Scanner type
1D/2D
Sensor type
LED
Linear (1D) barcodes supported
Codabar, Code 128, Code 93, Code 39, EAN-8, EAN-13, JAN-13, JAN-8, GS1 DataBar Expanded, GS1 DataBar Omnidirectional, GS1 Databar Limited, Interleaved 2 of 5, ISBT 128, Trioptic, UPC-A, UPC-E
2D (matrix & stacked) barcodes supported
Aztec Code, Composite Codes, Data Matrix, DotCode, Grid Matrix Code, Han Xin, MaxiCode, MicroPDF417, Micro QR Code, PDF417, QR Code
Optical sensor resolution (W x H)
1280 x 960 pixels
Light levels (direct sunlight)
0 - 100000 lx
Tilt reading angle
33.5 - 44.5°
Ports & interfaces
Connectivity technology
Wireless
Standard interfaces
Bluetooth
Wireless range
10 m
Bluetooth version
2.1+EDR
Performance
International Protection (IP) code
IP67
Protection features
Drop resistant
LED indicators
Yes
Product colour
Black, Green
Country of origin
China
Power
Power source type
Battery
Battery technology
Lithium-Ion (Li-Ion)
Charging port type
USB Type-C
Battery capacity
700 mAh
Battery voltage
3.7 V
Number of reads per charge
500
Battery life
25 h
Charging time
8 h
Operational conditions
Operating temperature (T-T)
0 - 45 °C
Storage temperature (T-T)
-40 - 70 °C
Operating relative humidity (H-H)
0 - 95%
Storage relative humidity (H-H)
0 - 60%
Drop resistance
3.1 m
Battery
Battery weight
12.5 g
Battery capacity
2.59 Wh
Rechargeable battery
Yes
Number of battery cells
1
Technical details
Warranty period
1 year(s)
Compliance certificates
UKCA, RoHS, Federal Communications Commission (FCC), CE
Other features
Mobile operating systems supported
iOS
Information
| Part Number: | CX4184-3251 |
