Product Details
Scanning
Type
Fixed bar code reader
Scanner type
1D/2D
Linear (1D) barcodes supported
Codabar, Code 128, Code 39, Code 93, JAN-8, JAN-13, EAN-13, EAN-8, GS1 DataBar Expanded, GS1 Databar Limited, GS1 DataBar Omnidirectional, Industrial 2 of 5, Interleaved 2 of 5, UPC-A, UPC-E
2D (matrix & stacked) barcodes supported
Aztec Code, Data Matrix, Han Xin, MaxiCode, MicroPDF417, Micro QR Code, PDF417, QR Code
Ports & interfaces
Connectivity technology
Wireless
Standard interfaces
Bluetooth
Near Field Communication (NFC)
Yes
Performance
LED indicators
Yes
Country of origin
China
Power
Power source type
Battery
Battery technology
Lithium-Ion (Li-Ion)
Battery capacity
1800 mAh
Battery voltage
3.7 V
Number of reads per charge
300
Battery life
25 h
Charging time
4 h
Weight & dimensions
Width
92.7 mm
Depth
92.7 mm
Height
74.2 mm
Operational conditions
Operating temperature (T-T)
0 - 45 °C
Storage temperature (T-T)
-40 - 70 °C
Operating relative humidity (H-H)
0 - 95%
Battery
Battery weight
39 g
Battery capacity
3.7 Wh
Rechargeable battery
Yes
Number of battery cells
1
Technical details
Compliance certificates
RoHS, Federal Communications Commission (FCC), UL, CE, UKCA
Other features
Windows operating systems supported
Yes
Mobile operating systems supported
Android, iOS
Information
| Part Number: | TX4109-3176 |
