Product Details
Introduction
Create high-resolution 4K x 2K connections with HBR2 support between your DisplayPort equipped devicesThe StarTech.com Advantage
Technical details
Harmonized System (HS) code
84733080
Compliance certificates
RoHS
Features
Connector 1 form factor
Straight
Connector 2 form factor
Straight
Connector contacts plating
Nickel
DisplayPort version
1.2
Maximum resolution
3840 x 2400 pixels
Supported graphics resolutions
3840 x 2400,2560 x 1600 (WQXGA)
Maximum refresh rate
120 Hz
HDCP
Y
DisplayPort Content Protection (DPCP)
Y
Cable length
3 m
Connector 1
DisplayPort
Connector 2
DisplayPort
Connector 1 gender
Male
Connector 2 gender
Male
Latching connectors
Y
Product colour
Black
Cable rating
CMG (CM)
Cable shielding
Aluminum mylar foil
Jacket material
Polyvinyl chloride (PVC)
AWG wire size
28
Bandwidth
21600 MB/s
Plug and Play
Y
Multi-Stream Transport (MST)
Y
Number of conductors
19
Sustainability
Sustainability certificates
RoHS
Packaging data
Cable diameter
7.3 mm
Weight
210 g
Quantity per pack
1 pc(s)
Package width
200 mm
Package depth
220 mm
Package height
34 mm
Package weight
215 g
Logistics data
Master (outer) case width
330 mm
Master (outer) case length
500 mm
Master (outer) case height
280 mm
Products per master (outer) case
50 pc(s)
Information
| Part Number: | DISPLPORT10L |
