STARTECH.COM Hdmi Video Switch - 4 Port 3x Hdmi And 1x DisplayPort - 4k 60hz

STARTECH.COM Hdmi Video Switch - 4 Port 3x Hdmi And 1x DisplayPort - 4k 60hz

£65.26 (incl. VAT)

Qty:

Add to basket

Part Number:	VS421HDDP
	In Stock
	Delivery: 1 - 2 days

Product Details

Introduction

Multi-Port HDMI Switch Box | Automatic Switcher | IR Remote Control

This 4-input HDMI video switch lets you share an HDMI 2.0 display or projector with three HDMI video sources and one DisplayPort video source.

Enjoy Astonishing Picture Quality

The multi-port HDMI switch lets you deliver the capabilities of your HDMI 2.0 video sources to your UHD 4K60 display. Unlike many 4K switches that only support a 30Hz refresh rate, this switcher box works with HDMI 2.0 displays with output resolutions of up to 4096 x 2160 at 60Hz.

With full support for HDMI 2.0 devices and 4:4:4 chroma subsampling, this 4K HDMI video switcher supports a bandwidth up to 18Gbps. As well, the switch supports DisplayPort 1.2 with HBR2, making it ideal for high-resolution computer tasks.

Flexible Input Options

This multi-port video switcher offers four input options, including one DisplayPort and three HDMI ports, enabling you to switch from one of four sources to your HDMI video display. The mix-and-match input options provide users with a flexible solution so they are not limited to one specific input.

Hassle-Free Operation with Automatic Switching

This HDMI switcher box ensures effortless operation with automatic switching that detects and selects a newly connected device. It's perfect for automatically switching to a 4K media player such as a 4K UHD Blu-ray player as soon as it's switched on.

This automatic HDMI switch also supports manual operation, using the included IR remote control or the built-in front-panel toggle switch.

VS421HDDP is backed by a 2-year StarTech.com warranty and free lifetime technical support.

The StarTech.com Advantage

- Experience astonishing picture quality with support for resolutions up to 4K 60Hz
- Hassle-free operation with automatic 4-port switching and an included IR remote control
- Unique input combination with both HDMI and DisplayPort ports

Logistics data

Master (outer) case width 354 mm

Master (outer) case length 508 mm

Master (outer) case height 302 mm

Products per master (outer) case 28 pc(s)

Technical details

Compliance certificates RoHS

Harmonized System (HS) code 85176990

Sustainability certificates RoHS

Ports & interfaces

Video port type HDMI/DisplayPort

HDMI version 2.0

HDMI in 3

Number of HDMI outputs 1

DisplayPorts quantity 1

3.5 mm (1/8-inch) in Y

DC-in jack Y

Features

Product colour Black

HDCP Y

Material Metal

Maximum refresh rate 60 Hz

Supported graphics resolutions 1280 x 720 (HD 720),1920 x 1080 (HD 1080),1920 x 1200 (WUXGA),2560 x 1600 (WQXGA),3840 x 2160,4096 x 2160

LED indicators Y

Maximum resolution 4096 x 2160 pixels

Audio output channels 7.1 channels

HDCP version 2.2

Power

AC input voltage 100 - 240 V

AC adapter input current 0.3 A

AC adapter output voltage 5 V

AC adapter output current 1 A

Power plug type Type M

Certificates

Certification CE, FCC, REACH

Weight & dimensions

Width 66 mm

Depth 100 mm

Height 20 mm

Weight 300 g

Packaging data

Package width 160 mm

Package depth 125 mm

Package height 65 mm

Package weight 400 g

Packaging content

Remote control included Y

Manual Y

Mounting brackets included Y

Plug adapter type NA/JP, UK, EU, ANZ

Screws included Y

Operational conditions

Operating temperature (T-T) 0 - 45 °C

Storage temperature (T-T) -20 - 70 °C

Operating relative humidity (H-H) 10 - 90%
