Product Details
Features
Cable length
5 m
Connector 1
LC
Connector 2
LC
Connector 1 gender
Male
Connector 2 gender
Male
Cable type
LOMM
Fibre optic type
OM4
Product colour
Aqua colour
Full duplex
Yes
Core diameter
50 µm
Cladding diameter
125 µm
Fiber mode structure
Multi-mode
Wavelengths supported
850,1300 nm
Data transfer rate
100 Gbit/s
Jacket material
Low smoke zero halogen (LSZH)
Logistics data
Master (outer) case width
410 mm
Master (outer) case length
410 mm
Master (outer) case height
430 mm
Products per master (outer) case
200 pc(s)
Packaging data
Package width
198 mm
Package depth
168 mm
Package height
19 mm
Quantity per pack
1 pc(s)
Operational conditions
Operating temperature (T-T)
-20 - 60 °C
Storage temperature (T-T)
-20 - 60 °C
Technical details
Sustainability compliance
Yes
Sustainability certificates
CE
Compliance certificates
CE
Weight & dimensions
Cable diameter
2.9 mm
Bending radius
6 cm
Information
| Part Number: | 450FBLCLC5SW |
