STARTECH.COM Vesa Certified DisplayPort Cable - 10 Pack - DisplayPort 1.2 Cord With Latches 4k 6 2m

£71.44

Part Number: DISPL2M10PK
Delivery: 1 - 2 days

Product Details

Introduction

Set up multiple 4K UHD connections using this DisplayPort Cable 10 Pack

Faciliate multi-monitor setups using this DisplayPort 1.2 Cable 10-Pack. This cable facilitates high bandwidth video and multi-channel audio and is ideal for 4K workstations, docks, and high performance GPUs. Connect a 4K 60Hz UHD DisplayPort monitor to a host computer or MST hub.

Seamless Compatibility

For seamless operation between DisplayPort-enabled devices, the DisplayPort 1.2 Cable is VESA Certified for guaranteed DP 1.2 and backward compatibility with DP 1.1.

Durable Design

This DisplayPort cable features a flexible TPE outer jacket and can be routed around corners and desk edges. Robust strain reliefs enable convenient positioning of the cable, and latching gold-plated DP connectors attach securely to prevent accidental disconnection.

Supported DisplayPort 1.2 Features:

The Certified DisplayPort Cable supports the following DP 1.2 features:

• Resolutions up to 4K 60Hz, using a compatible DP source and display
• Supports high refresh rates including 1080p 120Hz and 1440p 75Hz
• High-Bandwidth Digital Content Protection (HDCP) for a secure connection between source and display
• Multi-Stream Transport (MST) for daisy-chaining multiple monitors
• 8 Uncompressed Digital Audio Channels
• Backward compatible with DP 1.1

This DP 1.2 Cable is constructed with braided aluminum mylar shielding to minimize EMI for clear, consistent audio/video output and long-term reliable performance.

The StarTech.com Advantage

Features

Connector 1 form factor Straight
Connector 2 form factor Straight
Connector contacts plating Nickel
Maximum resolution 3840 x 2160 pixels
Maximum refresh rate 120 Hz
HDCP Yes
Cable length 2 m
Connector 1 DisplayPort
Connector 2 DisplayPort
Connector 1 gender Male
Connector 2 gender Male
Latching connectors Yes
Product colour Black
Cable rating CMG (CM)
Cable shielding Aluminum mylar foil
Jacket material Thermoplastic elastomer (TPE)
AWG wire size 28
Data transfer rate 21.6 Gbit/s
Multi-Stream Transport (MST) Yes
Number of conductors 19
Cable type Round cable

Operational conditions

Operating temperature (T-T) 0 - 40 °C
Storage temperature (T-T) -20 - 70 °C
Operating relative humidity (H-H) 10 - 85%

Packaging data

Cable diameter 7.3 mm
Weight 134 g
Quantity per pack 10 pc(s)
Package width 350 mm
Package depth 460 mm
Package height 100 mm
Package weight 1.4 kg

Technical details

Compliance certificates CE, RoHS

Logistics data

Master (outer) case width 320 mm
Master (outer) case length 500 mm
Master (outer) case height 210 mm
Products per master (outer) case 5 pc(s)

Information

Part Number: DISPL2M10PK
