STARTECH.COM Active DisplayPort Cable 4k/8k Vesa-certified Active Dp 1.4 7m

STARTECH.COM Active DisplayPort Cable 4k/8k Vesa-certified Active Dp 1.4 7m

£79.00 (incl. VAT)

Qty:

Add to basket

Part Number:	DP14A-7M-DP-CABLE
	In Stock
	Delivery: 1 - 2 days

Product Details

Introduction

Facilitate a longer 8K connection without requiring an external power sourceConnect a 4K/8K DisplayPort 1.4-enabled monitor to a source or MST-enabled hub, using this VESA-Certified Active DisplayPort 1.4 Cable. The active signal booster delivers reliable audio and 8K video output at up to 25ft (7.6m) without a DisplayPort repeater and external power source. This active DP 1.4 cable is unidirectional with conveniently labeled connectors for source and display to simplify setup.VESA-Certified DP8KFor seamless performance and compatibility between DisplayPort-enabled devices, the Active DisplayPort Cable is VESA Certified, for guaranteed DP 1.4 support and backward compatibility with DP 1.3/1.2Durable DesignThis long DisplayPort cable features a flexible TPE outer jacket to reduce wear from corner bends and long cable runs. Robust strain reliefs enable soft and flexible bends, for convenient positioning of the cable. The latching DP connectors are gold plated for improved conductivity and anti-tarnish properties, and attaches securely to the device to prevent accidental disconnection.Supported DisplayPort 1.4 Features:This 8K DisplayPort cable supports all DP 1.4 features:• Resolutions up to 8K 60Hz, 4K 120Hz, 1440p 240Hz with a compatible DP source and display• HDCP 2.2 support• High Bit Rate 3 (HBR3) bandwidth of 32.4Gbps• High Dynamic Range 10 (HDR10)• Display Stream Compression 1.2 (DSC 1.2)• Multi-Stream Transport (MST) for daisy-chaining multiple monitors• 32 Uncompressed Digital Audio Channels• Backward compatible with 5K 60Hz, 4K 120Hz and previous DP versionsThe Active DP Cable is constructed with aluminum-mylar shielding to minimize EMI interference for clear and reliable audio/video output. This VESA-certified DP cable is designed for long-term reliability, and is the ideal solution for setting up boardrooms, video walls, and TV signage.The StarTech.com Advantage

Features

Connector 1 form factor Straight

Connector 2 form factor Straight

Connector contacts plating Gold

DisplayPort version 1.4

Maximum resolution 7680 x 4320 pixels

Supported graphics resolutions 3840 x 2160, 7680 x 4320

Maximum refresh rate 144 Hz

HDCP Y

HDCP version 2.2

Display Stream Compression (DSC) Y

Display Stream Compression (DSC) version 1.2

Cable length 7.7 m

Connector 1 DisplayPort

Connector 2 DisplayPort

Connector 1 gender Male

Connector 2 gender Male

Product colour Black

Cable material Copper

Cable shielding Aluminum mylar foil

Jacket material Thermoplastic elastomer (TPE)

AWG wire size 24/28

Data transfer rate 25.92 Gbit/s

Bandwidth 32400 MB/s

HBR3 support Y

Multi-Stream Transport (MST) Y

Fire-resistance rating VW-1

Operational conditions

Operating temperature (T-T) 0 - 50 °C

Storage temperature (T-T) -20 - 60 °C

Operating relative humidity (H-H) 0 - 85%

Sustainability

Sustainability compliance Y

Sustainability certificates RoHS

Packaging data

Cable diameter 7.5 mm

Package width 330 mm

Package depth 252 mm

Package height 100 mm

Package weight 500 g

Logistics data

Master (outer) case width 430 mm

Master (outer) case length 380 mm

Master (outer) case height 290 mm

Products per master (outer) case 20 pc(s)

Technical details

Compliance certificates RoHS

Information

Part Number:

DP14A-7M-DP-CABLE
