Product Details
Introduction
Slim DP Monitor Cable | 8K@60Hz | HBR3 | HDR | Gold-Plated | Lifetime WarrantyThe StarTech.com Advantage
Technical details
Compliance certificates
RoHS
Harmonized System (HS) code
84733080
Features
Connector 1 form factor
Straight
Connector 2 form factor
Straight
Connector contacts plating
Gold
DisplayPort version
1.4
Maximum resolution
7680 x 4320 pixels
Supported graphics resolutions
2560 x 1600 (WQXGA),3840 x 2160,7680 x 4320
Maximum refresh rate
120 Hz
HDCP
Y
Cable length
2 m
Connector 1
DisplayPort
Connector 2
DisplayPort
Connector 1 gender
Male
Connector 2 gender
Male
Latching connectors
Y
Product colour
Black
Cable shielding
Aluminum mylar foil
Jacket material
Polyvinyl chloride (PVC)
AWG wire size
34
High Dynamic Range (HDR) supported
Y
Bandwidth
32400 MB/s
Plug and Play
Y
HBR3 support
Y
Multi-Stream Transport (MST)
Y
Number of conductors
19
Fire-resistance rating
VW-1
Certification
CE
Sustainability
Sustainability certificates
RoHS
Packaging data
Cable diameter
4.5 mm
Weight
252 g
Quantity per pack
1 pc(s)
Package width
250 mm
Package depth
330 mm
Package height
10 mm
Package weight
270 g
Logistics data
Master (outer) case width
355 mm
Master (outer) case length
550 mm
Master (outer) case height
270 mm
Products per master (outer) case
30 pc(s)
Information
| Part Number: | DP14MM2M |
