Product Details
Introduction
Allows a DisplayPort connection to be mounted on a secure easily accessible panelThe StarTech.com Advantage
Technical details
Compliance certificates
CE, RoHS
Harmonized System (HS) code
84733080
Features
Connector 1 form factor
Straight
Connector 2 form factor
Straight
Connector contacts plating
Nickel
DisplayPort version
1.2
Maximum resolution
4096 x 2160 pixels
Maximum refresh rate
60 Hz
Cable length
0.9 m
Connector 1
DisplayPort
Connector 2
DisplayPort
Connector 1 gender
Male
Connector 2 gender
Female
Latching connectors
Y
Product colour
Black
Cable rating
CMG (CM)
Jacket material
Polyvinyl chloride (PVC)
AWG wire size
28
Bandwidth
21600 MB/s
Plug and Play
Y
Multi-Stream Transport (MST)
Y
Number of conductors
20
Operational conditions
Operating temperature (T-T)
-10 - 40 °C
Storage temperature (T-T)
-10 - 80 °C
Operating relative humidity (H-H)
0 - 85%
Sustainability
Sustainability certificates
CE, RoHS
Packaging data
Weight
83 g
Package width
200 mm
Package depth
220 mm
Package height
25 mm
Package weight
88 g
Logistics data
Master (outer) case width
330 mm
Master (outer) case length
500 mm
Master (outer) case height
250 mm
Products per master (outer) case
120 pc(s)
Information
| Part Number: | DPPNLFM3PW |
