Product Details
Features
Cable length
1 m
Connector 1
HDMI Type A (Standard)
Connector 2
HDMI Type A (Standard)
Connector 1 gender
Male
Connector 2 gender
Male
Connector 1 form factor
Straight
Connector 2 form factor
Straight
HDMI cable type
Ultra High Speed HDMI cable
Product colour
Black
HDMI version
2.1
Supported graphics resolutions
10240 x 4320, 7680 x 4320, 3840 x 2160, 2560 x 1440
Dolby technologies
Dolby TrueHD, Dolby Atmos, DTS:X
HDCP
Yes
HDCP version
2.3
Data transfer rate
48 Gbit/s
High Dynamic Range (HDR) supported
Yes
High Dynamic Range (HDR) technology
High Dynamic Range 10+ (HDR10 Plus), Dolby Vision
Supported digital audio channels (uncompressed)
7.1, 32
Maximum refresh rate
240 Hz
AWG wire size
34
Connector contacts plating
Gold
Cable type
Round cable
Cable jacket material
Thermoplastic elastomer (TPE)
Enhanced Audio Return Channel (eARC)
Yes
Cable shielding
Aluminum mylar foil
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-20 - 70 °C
Operating relative humidity (H-H)
10 - 90%
Certificates
Compliance certificates
RoHS, CE
Weight & dimensions
Cable diameter
4 mm
Weight
92 g
Packaging data
Package width
190 mm
Package depth
110 mm
Package height
23 mm
Package weight
109 g
Quantity per pack
1 pc(s)
Logistics data
Master (outer) case width
410 mm
Master (outer) case length
275 mm
Master (outer) case height
265 mm
Products per master (outer) case
40 pc(s)
Information
| Part Number: | HDMI21-CBL-SLIM-1M |
