STARTECH.COM Patch Cable - CAT6a - S/ftp - Snagless - 1.5m - Blue (lszh)

£6.31

Part Number: NLBL-150-CAT6A-PATCH
Delivery: 1 - 2 days

Product Details

Introduction

LSZH | 10GbE | 100W PoE++ | Snagless RJ-45Cat6a Ethernet Low-Smoke Zero-Halogen (LSZH) Shielded cables support Multi-Gigabit/Multi-speed 1/2.5/5Gbps/10Gbp connections. It offers robust protection against electromagnetic interference (EMI/RFI) and noise, ensuring a fast, safe, and reliable network.Low-Smoke Zero-Halogen (LSZH) CAT6A Ethernet CableLSZH Cat6a Network Cables are more eco-friendly than PVC cables. In the event of a fire, LSZH cables produce low levels of corrosive fumes and smoke. Low levels of acrid combustion pollutants promote increased visibility, resulting in safe and quick building evacuations by staff and first responders.100W Power over Ethernet (PoE++)This high performance Ethernet cable complies with the IEEE 802.3bt-2018 standard. It supports 100W PoE++, providing ample power to Type 4 PoE devices.RJ45 Connectors with Snagless ClipsThe Cat6a cable features snag-less connectors. Snagless molded boots protect the tab/latch on each RJ45 connector. The boots prevent the cable from snagging during cable routing and/or installation into network devices.The molded boots feature integrated strain reliefs that prevent sharp connector/cable angles at the termination points.This product is backed for life, including free lifetime 24/5 multi-lingual technical assistance.The StarTech.com Advantage

Features

Product colour Blue
Cable length 1.5 m
Cable standard Cat6a
Cable shielding S/FTP (S-STP)
Connector 1 RJ-45
Connector 2 RJ-45
Connector 1 gender Male
Connector 2 gender Male
Connector 1 form factor Straight
Connector 2 form factor Straight
Connector shielding Y
Jacket material Low smoke zero halogen (LSZH)
Cable shape Round
Conductor type Stranded
Conductor material Copper
Cabling technology 10GBase-T
AWG wire size 27
Data transfer rate 10000 Mbit/s
Frequency 500 MHz
Power over Ethernet (PoE) Y
Power over Ethernet (PoE) type supported PoE++ (4PPoE)
Total Power over Ethernet (PoE) budget 100 W
Snagless cable boot Y
Plug and Play Y

Weight & dimensions

Weight 58.7 g

Packaging data

Quantity per pack 1 pc(s)
Package width 220 mm
Package depth 190 mm
Package height 12 mm
Package weight 67.4 g

Technical details

Sustainability compliance Y
Sustainability certificates CE, RoHS
Compliance certificates CE, RoHS

Logistics data

Master (outer) case width 430 mm
Master (outer) case length 380 mm
Master (outer) case height 290 mm
Products per master (outer) case 100 pc(s)

Information

Part Number: NLBL-150-CAT6A-PATCH
