Product Details
Features
Cable length
10 m
Connector 1
HDMI Type A (Standard)
Connector 2
HDMI Type A (Standard)
Connector 1 gender
Male
Connector 2 gender
Male
Connector 1 form factor
Straight
Connector 2 form factor
Straight
Product colour
Black
HDMI version
2.0
Dolby technologies
Dolby TrueHD, Dolby Atmos, Dolby Digital Plus
Audio Return Channel (ARC)
Y
HDMI Ethernet channel
Y
HDCP
Y
HDCP version
2.2
High Dynamic Range (HDR) supported
Y
High Dynamic Range (HDR) technology
High Dynamic Range 10 (HDR10)
Supported digital audio channels (uncompressed)
32
AWG wire size
28
Connector contacts plating
Gold
Cable material
Copper
Cable type
Round cable
Cable jacket material
Thermoplastic elastomer (TPE)
Quantity per pack
1 pc(s)
Weight & dimensions
Cable diameter
7.5 mm
Weight
700 g
Package width
330 mm
Package depth
252 mm
Package height
120 mm
Package weight
700 g
Technical details
Sustainability compliance
Y
Sustainability certificates
RoHS, CE
Compliance certificates
RoHS, CE
Logistics data
Master (outer) case width
430 mm
Master (outer) case length
380 mm
Master (outer) case height
290 mm
Products per master (outer) case
16 pc(s)
Operational conditions
Operating temperature (T-T)
0 - 50 °C
Storage temperature (T-T)
0 - 50 °C
Operating relative humidity (H-H)
0 - 85%
Information
| Part Number: | RH2A-10M-HDMI-CABLE |
