Product Details
Features
Cable length
7 m
Connector 1
HDMI Type A (Standard)
Connector 2
HDMI Type A (Standard)
Connector 1 gender
Male
Connector 2 gender
Male
Connector 1 form factor
Straight
Connector 2 form factor
Straight
Product colour
Black
HDMI version
2.0
Dolby technologies
Dolby Atmos, Dolby Digital Plus, Dolby TrueHD
Audio Return Channel (ARC)
Y
HDMI Ethernet channel
Y
HDCP
Y
HDCP version
2.2
High Dynamic Range (HDR) supported
Y
High Dynamic Range (HDR) technology
High Dynamic Range 10 (HDR10)
Supported digital audio channels (uncompressed)
32
Maximum refresh rate
60 Hz
AWG wire size
28
Connector contacts plating
Gold
Cable material
Copper
Cable type
Round cable
Cable jacket material
Thermoplastic elastomer (TPE)
Cable shielding
Aluminum mylar foil
Quantity per pack
1 pc(s)
Weight & dimensions
Cable diameter
7.5 mm
Weight
500 g
Package width
330 mm
Package depth
252 mm
Package height
100 mm
Package weight
500 g
Technical details
Sustainability compliance
Y
Sustainability certificates
CE, RoHS
Compliance certificates
CE, RoHS
Logistics data
Master (outer) case width
430 mm
Master (outer) case length
380 mm
Master (outer) case height
290 mm
Products per master (outer) case
20 pc(s)
Information
| Part Number: | RH2A-7M-HDMI-CABLE |
