Introduction
This USB-CT to fiber-optic converter lets you utilize the USB 3.0 (Type-CT) port on your laptop or tablet to provide a secure fiber network connection. Windows® and Mac compatible, the network adapter provides a Gigabit Ethernet (1000 Mbps) optical network connection for portable laptops or tablets, or systems without expansion slots.
A flexible solution with an open SFP slot
The open SFP slot enables you to use your preferred SFP transceiver module to meet your networking needs - use an SFP with your desired wavelength, distance, connection type to achieve an efficient network solution. (SFP sold separately.)
Secure fiber-to-the-desk connectivity
This USB to fiber-optic converter provides reliable fiber connectivity, while protecting your network from problems with electronic interference - a common issue with RJ45 networks. Fiber-to-the-desk connectivity (FTTD) maximizes network security, reducing the risk of data leaks for sensitive information, without compromising network speed and reliability.
Easy portability
Compact and portable, this USB-C to fiber-optic converter is powered directly from the USB port.
Plug and play
Get up and running quickly. The USB to fiber-optic converter supports certified drivers for Windows, Mac and Linux®. Once the adapter is plugged into a USB-C port, you simply install the drivers and the adapter is ready to transmit over a fiber network.
The US1GC30SFP is backed by a StarTech.com 2-year warranty and free lifetime technical support.
Sustainability
Sustainability compliance
Yes
Sustainability certificates
RoHS
Logistics data
Master (outer) case width
308 mm
Master (outer) case length
590 mm
Master (outer) case height
366 mm
Products per master (outer) case
40 pc(s)
Technical details
Compliance certificates
CE, RoHS
Ports & interfaces
Connectivity technology
Wired
Host interface
USB Type-C
Interface
Fiber
Fiber ports quantity
1
Fiber optic connector
SFP
USB version
3.2 Gen 1 (3.1 Gen 1)
Other features
Harmonized System (HS) code
85176990
Housing material
Plastic
Cable length
0.195 m
Network
Maximum data transfer rate
1000 Mbit/s
Networking standards
IEEE 802.1Q,IEEE 802.3z
Fiber ethernet cabling technology
1000BASE-SX,1000BASE-LX
Wake-on-LAN ready
Y
Full duplex
Y
Jumbo frames support
Y
Jumbo frames
9000
VLAN tagging
Y
Design
Product colour
Black
Internal
N
Chipset
Realtek - RTL8153-VB-CG, Microsemi - VSC8211XVW
Plug and Play
Y
LED indicators
Activity, Link, Power
Certification
CE, FCC
Power
System requirements
Windows operating systems supported
Windows 10,Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 IOT Core,Windows 10 Pro,Windows 10 Pro x64,Windows 10 x64,Windows 7,Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate,Windows 7 Ultimate x64,Windows 7 x64,Windows 8,Windows 8 Enterprise,Windows 8 Enterprise x64,Windows 8 Pro,Windows 8 Pro x64,Windows 8 x64,Windows 8.1,Windows 8.1 Enterprise,Windows 8.1 Enterprise x64,Windows 8.1 Pro,Windows 8.1 Pro x64,Windows 8.1 x64
Mac operating systems supported
Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.9 Mavericks
Linux operating systems supported
Y
Server operating systems supported
Windows Server 2008,Windows Server 2012,Windows Server 2016,Windows Server 2019
Operational conditions
Operating temperature (T-T)
0 - 60 °C
Storage temperature (T-T)
-10 - 70 °C
Operating relative humidity (H-H)
5 - 90%
Weight & dimensions
Width
55 mm
Depth
260 mm
Height
20 mm
Weight
100 g
Packaging data
Package width
170 mm
Package depth
142 mm
Package height
30 mm
Package weight
104 g
