Product Details
Ports & interfaces
Card reader integrated
No
DC-in jack
No
Host interface
USB 3.2 Gen 1 (3.1 Gen 1) Type-B
Hub interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
4
Ports quantity
4
Terminal block port
Yes
Features
Data transfer rate
5000 Mbit/s
Product colour
Black
Housing material
Metal
LED indicators
Power, Status
Plug and Play
Yes
Network
UASP support
Yes
Weight & dimensions
Width
114 mm
Depth
67 mm
Height
26 mm
Packaging data
Package width
213 mm
Package depth
149 mm
Package height
51 mm
Package weight
450 g
Packaging content
Cables included
USB Type-A to USB Type-B
DIN rail kit included
Yes
Quick start guide
Yes
Operational conditions
Operating temperature (T-T)
0 - 60 °C
Storage temperature (T-T)
-20 - 75 °C
Operating relative humidity (H-H)
5 - 95%
Sustainability
Sustainability compliance
Yes
Sustainability certificates
CE, Trade Agreements Act (TAA)
Performance
Mean time between failures (MTBF)
131406 h
Logistics data
Master (outer) case width
520 mm
Master (outer) case length
430 mm
Master (outer) case height
270 mm
Products per master (outer) case
25 pc(s)
Other features
Chipset
VIA - VL817-Q7 C0
Technical details
Compliance certificates
CE, Trade Agreements Act (TAA)
Information
| Part Number: | 5G4AINDRM-USB-A-HUB |
