STARTECH.COM DisplayPort KVM Switch 2-port USB 3.0

STARTECH.COM DisplayPort KVM Switch 2-port USB 3.0

£355.77 (incl. VAT)

Qty:

Add to basket

Part Number:	P2AD122-KVM-SWITCH
	In Stock
	Delivery: 1 - 2 days

Product Details

Introduction

Share a mouse, keyboard, USB 5Gbps hub, and 4K 60Hz DisplayPort display between two DisplayPort-enabled computers, featuring EDID Emulation and HDCP engine

This DisplayPort KVM Switch enables users to switch between two desktops equipped with USB-A and DisplayPort. It allows sharing of a 4K 60Hz DisplayPort monitor, a keyboard, mouse, two USB 5Gbps devices, a stereo audio output device, and two additional USB 2.0 devices.

EDID Control for Display Compatibility

This KVM supports resolutions up to 4K 60Hz, making it ideal for applications such as CAD/CAM, video editing, and content creation. It has been extensively tested to ensure compatibility across a wide range of devices and environments. HDCP Engine enables transmission of protected content. It also features flexible EDID management with options to retain, auto-detect, or default, reducing resolution mismatch issues and simplifying display-related troubleshooting for IT teams.

Customizable Switching

This universal KVM switch offers hotkey and push-button switching. Hotkeys allow independent switching of audio and video, enabling audio playback from one computer while controlling another. An audible buzzer confirms hotkey inputs, and LEDs provide visual status feedback for the selected host.

No Drivers or Software Required

The TAA-compliant KVM Switch offers universal compatibility and works with all operating systems, including Windows, macOS, ChromeOS, and Linux. The KVM provides BIOS/UEFI control and is compatible with all hardware platforms, including Intel, AMD, and Apple Silicon (M-Series).

Reliable Performance

The rugged metal case helps prevent electromagnetic interference (EMI). 4kV Air/4kV Contact ESD protection enhances the reliability and longevity of the KVM. The included set of rubber feet protect the work surface from scratches and keep KVM in place during operation.

Ports & interfaces

Number of computers controlled 2

Keyboard port type USB

Mouse port type USB

Video port type DisplayPort

DisplayPorts quantity 2

DisplayPort version 1.2

USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity 2

Console ports 3.5mm headphone, DisplayPort, USB A

Console USB ports quantity 4

Console DisplayPorts ports quantity 1

USB hub Yes

USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity 2

Audio connections Yes

Number of microphone inputs 2

DC-in jack Yes

Performance

HD type 4K Ultra HD

Maximum resolution 3840 x 2160 pixels

Data transfer rate (max) 5 Gbit/s

Scan interval 3,8,15,30 s

Design

Rack mounting No

Product colour Black

Housing material Steel

Maximum cable length 3 m

LED indicators Yes

Push button Yes

Hot keys Yes

Mean time between failures (MTBF) 130000 h

Display

Built-in display No

On Screen Display (OSD) No

Power

Power source DC

Input voltage 100 - 240 V

Input current 1 A

Output current 3 A

Power consumption (typical) 36 W

Power plug type Type M

Compatible power plug types AU, EU, UK

Sustainability

Compliance certificates Federal Communications Commission (FCC), RoHS, Trade Agreements Act (TAA)

Operational conditions

Operating temperature (T-T) 0 - 40 °C

Storage temperature (T-T) -20 - 60 °C

Operating relative humidity (H-H) 0 - 80%

Weight & dimensions

Width 100 mm

Depth 160 mm

Height 40 mm

Weight 640 g

Packaging data

Package width 238 mm

Package depth 184 mm

Package height 89 mm

Packaging content

AC adapter included Yes

Rubber feet Yes

Other features

IP control No

Logistics data

Master (outer) case width 397 mm

Master (outer) case length 257 mm

Master (outer) case height 300 mm

Products per master (outer) case 6 pc(s)

Information

Part Number:

P2AD122-KVM-SWITCH
