Product Details
Introduction
KVM with USB | Triple Monitor | TAA Compliant | USB 3.0 Hub | DisplayPort 1.2 | Digital & Analog AudioThe StarTech.com Advantage
Logistics data
Harmonized System (HS) code
85176200
Master (outer) case width
397 mm
Master (outer) case length
317 mm
Master (outer) case height
280 mm
Products per master (outer) case
6 pc(s)
Ports & interfaces
Number of computers controlled
2
Keyboard port type
USB
Mouse port type
USB
Video port type
DisplayPort
HDCP
Y
DisplayPorts quantity
9
DisplayPort version
1.2
Console ports
3.5mm headphone, DisplayPort, USB A
Console USB ports quantity
4
USB hub
Y
USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity
2
Audio connections
Y
Headphone outputs
3
DC-in jack
Y
Performance
HD type
4K Ultra HD
Maximum resolution
3840 x 2160 pixels
Video bandwidth
60 Hz
Scan interval
3,8,15,30 s
Daisy chain
N
Audio channels
5.1
Number of displays supported
3
Design
Product colour
Black
Housing material
Steel
LED indicators
Y
Push button
Y
Hot keys
Y
Mean time between failures (MTBF)
156000 h
Certification
CE, RoHS, FCC
Display
Built-in display
N
On Screen Display (OSD)
N
Power
AC input voltage
100 - 240 V
Input current
1 A
Output voltage
12 V
Output current
3 A
Power consumption (typical)
36 W
Power plug type
Type M
Compatible power plug types
AU, EU, JP, UK, US
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-10 - 60 °C
Operating relative humidity (H-H)
0 - 80%
Weight & dimensions
Width
160 mm
Depth
100 mm
Height
98 mm
Weight
850 g
Packaging data
Package width
238 mm
Package depth
189 mm
Package height
91 mm
Packaging content
Quick installation guide
Y
Rubber feet
Y
Other features
IP control
N
Information
| Part Number: | SV231TDPU34K |
