Product Details
Introduction
2x USB 3.2 Gen 2x1 (10Gbps) Type-A | 1x USB 3.2 Gen 2x1 (10Gbps) Type-C 2x1 | 2x USB 3.2 Gen 1x1 (5Gbps) IDCThe StarTech.com Advantage
Technical details
Compliance certificates
CE, RoHS
Sustainability certificates
CE, RoHS
Features
Harmonized System (HS) code
84733020
Chipset
ASMedia - ASM3142, Genesys Logic - GL3590
Data transfer rate (max)
10 Gbit/s
UASP support
Y
Ports & interfaces
Host interface
PCIe
Output interface
USB 3.2 Gen 2 (3.1 Gen 2)
Expansion card standard
PCIe 3.0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
1
Internal SATA ports quantity
1
Design
Internal
Y
Product colour
Red
Mean time between failures (MTBF)
1677495 h
Operational conditions
Operating temperature (T-T)
0 - 70 °C
Storage temperature (T-T)
-20 - 80 °C
Operating relative humidity (H-H)
15 - 90%
System requirements
Windows operating systems supported
Windows 10,Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 IoT Enterprise,Windows 10 Pro,Windows 10 Pro x64,Windows 10 x64,Windows 7,Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate x64,Windows 7 x64,Windows 8,Windows 8 Enterprise,Windows 8 Enterprise x64,Windows 8 Pro,Windows 8 Pro x64,Windows 8 x64,Windows 8.1,Windows 8.1 Enterprise,Windows 8.1 Enterprise x64,Windows 8.1 Pro,Windows 8.1 Pro x64,Windows 8.1 x64
Mac operating systems supported
Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 11.0 Big Sur
Server operating systems supported
Windows Server 2008 R2,Windows Server 2012 R2,Windows Server 2019
Weight & dimensions
Width
68.9 mm
Depth
102 mm
Height
14.4 mm
Weight
60 g
Packaging data
Mounting brackets included
Y
Quick installation guide
Y
Package width
140 mm
Package depth
175 mm
Package height
30 mm
Package weight
125 g
Logistics data
Products per master (outer) case
60 pc(s)
Master (outer) case width
370 mm
Master (outer) case length
375 mm
Master (outer) case height
500 mm
Information
| Part Number: | PEXUSB312A1C1H |
