Introduction
Seize the power to get more done when you sync your ViewBoard® interactive displays and wireless presentation display with the ViewSonic VPC25-P Series slot-in PC. Integrated with exceptional performance from Intel® 10th Gen Core™ processors, up to 16GB DDR4 memory, and up to 256GB of SSD storage, experience enhances computing performance to breeze through complex classes and collaborations. Plug into pure productivity with dual-band WiFi, Bluetooth 5.2, and a range of ports, including 4K HDMI, DP1.4, USB 3.0, and Gigabit LAN RJ45 for faster workflows.?
Tap into a productivity powerhouse?
Boost the interactive whiteboard with remarkable power and lightning-fast speed from Intel® 10th Gen Core™ processors, letting you zip through lessons and tutorials effortlessly. Integrated with Intel® WiFi 6 and Bluetooth 5.2, experience ultra-fast, versatile connectivity to facilitate remote and hybrid classes with ease.
Stability in every lesson
Teach and present without any worry about sudden disruptions. Built with the FinchGuard, a Watchdog timer software, the VPC25-P Series intuitively detects and recovers from system malfunctions seamlessly to maximise productivity.?
Stay cool and blaze through classes?
Equipped with a thermal control circuit and noise reduction capabilities, the fan within the device will dissipate much more heat in quieter acoustics of under 35 decibels for more conducive and longer lessons. ?
Boot up with total security?
Prevent malicious software and unwanted operating systems from loading during start-up with the optional Secure Boot in the BIOS setting. This stops existing errors from loading and keeps unauthorised personnel from accessing PC settings.
Efficient content management?
Synced with myViewBoard, an intuitive suite of software applications, the VPC25-P Series offers remote content sharing and engaging lesson delivery for enhanced interactivity and maximised productivity.?
Processor
Processor manufacturer
Intel
Processor family
Intel® Core™ i5
Processor generation
10th gen Intel® Core™ i5
Processor model
i5-10400T
Processor cores
6
Processor frequency
2 GHz
Processor boost frequency
3.6 GHz
Processor cache
12 MB
Configurable TDP-down
25 W
Configurable TDP-down frequency
1.3 GHz
Memory
Internal memory
8 GB
Maximum internal memory
8 GB
Internal memory type
DDR4-SDRAM
Storage
Total storage capacity
256 GB
Storage media
SSD
Optical drive type
No
Total SSDs capacity
256 GB
Number of SSDs installed
1
SSD capacity
256 GB
SSD interface
PCI Express, SATA III
SSD form factor
M.2
Graphics
Discrete graphics card
No
On-board graphics card
Yes
Discrete graphics card model
Not available
On-board GPU manufacturer
Intel
On-board graphics card family
Intel® UHD Graphics
On-board graphics card model
Intel® UHD Graphics 630
Network
Ethernet LAN
Yes
Ethernet LAN data rates
10,100,1000 Mbit/s
Wi-Fi
Yes
Top Wi-Fi standard
Wi-Fi 6 (802.11ax)
Bluetooth
Yes
Bluetooth version
5.2
Ports & interfaces
USB 2.0 ports quantity
2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
4
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
1
HDMI ports quantity
1
HDMI version
2.0
DisplayPorts quantity
1
Ethernet LAN (RJ-45) ports
1
Microphone in
Yes
Headphone outputs
1
Design
Chassis type
Slot-in PC
Colour name
Black
Product colour
Black
Performance
Motherboard chipset
Intel H410
Product type
Mini PC
Software
Operating system installed
Windows 10 Pro
Operating system architecture
64-bit
Bundled software
myViewBoard for Window /Adobe reader /Winflash /Watch Dog
Processor special features
Intel 64
Yes
Enhanced Intel SpeedStep Technology
Yes
Embedded options available
No
Intel Clear Video Technology
Yes
Intel VT-x with Extended Page Tables (EPT)
Yes
Idle States
Yes
Intel Stable Image Platform Program (SIPP)
No
Intel Trusted Execution Technology
No
Execute Disable Bit
Yes
Intel Software Guard Extensions (Intel SGX)
Yes
CPU configuration (max)
1
Intel Virtualization Technology for Directed I/O (VT-d)
Yes
Intel Virtualization Technology (VT-x)
Yes
Power
Power supply input voltage
110 - 240 V
Power supply input frequency
50 - 60 Hz
Operational conditions
Operating temperature (T-T)
-5 - 45 °C
Operating relative humidity (H-H)
10 - 90%
Certificates
Certification
cTUVus, FCC, FCC ID, IC ID, CE, RED, CB, BSMI, NCC, RoHS, ErP, REACH, WEEE
Compliance certificates
CB, CE, Federal Communications Commission (FCC), RCM, cTUVus
Sustainability
Sustainability certificates
CE, ErP, REACH, RoHS, WEEE
Weight & dimensions
Width
246.2 mm
Depth
32.2 mm
Height
263.4 mm
Weight
1.95 kg
Package width
350 mm
Package depth
90 mm
Package height
310 mm
Package weight
2.1 kg
Package width
265 mm
Package depth
212 mm
Package height
50 mm
Packaging content
Logistics data
Harmonized System (HS) code
84715000
Products per master (outer) case
8 pc(s)
Pallet gross width
120 cm
Pallet gross length
100 cm
Pallet gross height
180.6 cm
Harmonized System (HS) code
8471410000
