Product Details
Introduction
Elatec’s TWN4 Family allows users to read and write to almost any 125kHz/134.2kHz and 13.56MHz tags and/or labels. It supports all major transponders from various suppliers like ATMEL, EM, ST, NXP, TI, HID, LEGIC, INSIDE etc. and ISO standards like ISO14443A/B including layer 4 (T=CL), ISO15693, ISO18092 / ECMA-340 (NFC).
The new generation is a direct enhancement to the successful TWN3 family as it comes in the same mechanical dimensions (OEM PCB and Desktop Housing). All host communication can be done via USB, RS232 or serial TTL interface, the RF Frontend (e.g. Legic) can directly be accessed.
Technical details
Interface
USB
Working distance
10 cm
Certification
WEEE, RoHS, R&TTE, CE
Weight & dimensions
Weight
20 g
Operational conditions
Operating temperature (T-T)
-25 - 80 °C
Operating relative humidity (H-H)
-45 - 85%
Information
| Part Number: | 497N04035 |
