Product Details
Introduction
Kit Exit Guide Assembly TTP2000 & KR403.
Technical details
Compliance certificates
RoHS
Harmonized System (HS) code
84716070
Scanning
Type
Handheld bar code reader
Optical sensor resolution
1280 pixels
Scanner type
1D/2D
Sensor type
LED
Linear (1D) barcodes supported
Codabar, Code 11, Code 128, Code 39, Code 93, GS1-128 (UCC/EAN-128), MSI, Plessey, U.P.C.
2D (matrix & stacked) barcodes supported
Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code, TLC-39
Wavelength
610 nm
Tilt reading angle
-65 - 65°
Pitch reading angle
-65 - 65°
Yaw reading angle
-45 - 45°
Features
Print technology
Direct thermal
Compatibility
TTP2000, KR403
Ports & interfaces
Connectivity technology
Wired
Standard interfaces
RS-232, USB, Keyboard wedge
Ethernet LAN
Yes
Performance
International Protection (IP) code
IP67
Protection features
Dust resistant, Shock resistant, Water resistant
LED indicators
Yes
Product colour
Black, Green
Programming function
Yes
Power
Power source type
Battery
Battery technology
Lithium-Ion (Li-Ion)
Battery capacity
3100 mAh
Number of reads per charge
100000
Weight & dimensions
Width
132 mm
Depth
76 mm
Height
185 mm
Weight
305 g
Packaging data
Quantity per pack
1 pc(s)
Operational conditions
Operating temperature (T-T)
-30 - 50 °C
Storage temperature (T-T)
-40 - 70 °C
Operating relative humidity (H-H)
5 - 95%
Information
| Part Number: | DS3608-SR00003VZWW |
