Product Details
Scanning
Type
Built-in bar code reader
Scanner type
1D/2D
Linear (1D) barcodes supported
Codabar, Code 11, Code 128, Code 39, Code 93, GS1 DataBar, MSI, Plessey, UPC-A
2D (matrix & stacked) barcodes supported
Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code, TLC-39
Optical sensor resolution (W x H)
1920 x 1200 pixels
Light levels (direct sunlight)
0 - 86100 lx
Wavelength
660 nm
Ports & interfaces
Connectivity technology
Wired
Standard interfaces
USB
Performance
International Protection (IP) code
IP52
Product colour
Black
Power
Power source type
DC
Input voltage
5 V
Weight & dimensions
Width
152 mm
Depth
84 mm
Height
137 mm
Weight
577 g
Operational conditions
Operating temperature (T-T)
0 - 50 °C
Storage temperature (T-T)
-40 - 70 °C
Operating relative humidity (H-H)
20 - 95%
Information
| Part Number: | SP7201-SV00004ZCWW |
