Introduction
Near silent operation
The GS1900 Series includes both fan-less and built-in smart fan models. The smart fan is designed to automatically adjust speed based on device temperature. You can barely hear the sound while the switch is operating. It is ideal for your office environment.
Intelligent PoE+ powers more devices
PoE models (8HP/10HP/24EP/24HPv2/48HPv2) come with default PoE consumption mode which delivers only the actual power required by your networked devices, reserves the rest and optimizes its power budget. That means a single switch can power more APs, IP cameras and VoIP phones, ensuring a better ROI for your business. All of them support the IEEE 802.3at providing a maximum of 30W per port.
Speedy Gigabit performance—built for SMBs
The GS1900 is a series of switches with full non-blocking bandwidth of up to 1 Gbps per port. An ideal upgrade from an unmanaged switch, it’s a great choice for SMBs that want to enjoy high-speed business network applications at full wired non-blocking speed.
Management features
Switch type
Managed
Switch layer
L2
Quality of Service (QoS) support
Y
Web-based management
Y
System event log
Y
MIB support
RFC 1213 MIB II, RFC 2819 RMON (group 1, 2, 3, 9), RFC 1215 generic traps, RFC 1493 bridge
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity
8
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
SFP module slots quantity
2
Console port
RJ-45
Network
Networking standards
IEEE 802.1D, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
10G support
N
Copper ethernet cabling technology
10BASE-T, 100BASE-T, 1000BASE-T
VLAN support
Y
Virtual LAN features
Voice VLAN
Data transmission
Switching capacity
20 Gbit/s
Throughput
14.88 Mpps
MAC address table
8000 entries
Jumbo frames
9000
Security
DHCP features
DHCP client
IGMP snooping
Y
Security algorithms
802.1x RADIUS, SSL/TLS
MAC address filtering
Y
Protocols
Management protocols
SNMP, RMON, ICMP, Syslog
Design
Rack mounting
N
Product colour
Black
LED indicators
Y
Wall mountable
Y
Certification
CE, FCC, RCM, Class A, BSMI CNS 13438, LVD EN 62368-1, BSMI CNS 14336-1
Performance
Mean time between failures (MTBF)
800259 h
Power
Power source
AC
Power supply included
Y
AC input voltage
100 - 240 V
AC input frequency
50/60 Hz
Power consumption (max)
95.3 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)
Y
Power over Ethernet (PoE) ports quantity
8
Total Power over Ethernet (PoE) budget
77 W
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-40 - 70 °C
Operating relative humidity (H-H)
10 - 95%
Storage relative humidity (H-H)
10 - 95%
Weight & dimensions
Width
250 mm
Depth
104 mm
Height
27 mm
Weight
720 g
