Introduction
Near silent operation
The GS1900 Series includes both fan-less and built-in smart fan models. The smart fan is designed to automatically adjust speed based on device temperature. You can barely hear the sound while the switch is operating. It is ideal for your office environment.
Intelligent PoE+ powers more devices
PoE models (8HP/10HP/24EP/24HPv2/48HPv2) come with default PoE consumption mode which delivers only the actual power required by your networked devices, reserves the rest and optimizes its power budget. That means a single switch can power more APs, IP cameras and VoIP phones, ensuring a better ROI for your business. All of them support the IEEE 802.3at providing a maximum of 30W per port.
Speedy Gigabit performance—built for SMBs
The GS1900 is a series of switches with full non-blocking bandwidth of up to 1 Gbps per port. An ideal upgrade from an unmanaged switch, it’s a great choice for SMBs that want to enjoy high-speed business network applications at full wired non-blocking speed.
Easy and intuitive management
The Smart Managed GS1900 Series switch feature with web-based interface to manage advanced functions such as VLAN, QoS, IGMP Snooping, Link Aggregation (LAG), IPv6 and DoS prevention easily. Also, the user-friendly wizard helps to walk through setup, configuration and even advanced settings quickly.
Management features
Switch type
Managed
Switch layer
L2
Quality of Service (QoS) support
Y
Web-based management
Y
System event log
Y
MIB support
RFC 1213 MIB II, RFC 2819 RMON (group 1, 2, 3, 9),RFC 1215 generic traps, RFC 1493 bridge, Zyxel private common MIB
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity
24
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Power connector
AC-in jack
Network
Networking standards
IEEE 802.1D, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
10G support
N
Port mirroring
Y
Full duplex
Y
Flow control support
Y
Link aggregation
Y
Spanning tree protocol
Y
Ethernet LAN data rates
10,100,1000 Mbit/s
MAC address auto-learning supported
Y
VLAN support
Y
Virtual LAN features
Stacked VLAN, VLAN mapping
Data transmission
Switching capacity
48 Gbit/s
Forwarding rate
35.7 Mpps
MAC address table
8000 entries
Store-and-forward
Y
Jumbo frames support
Y
Jumbo frames
9000
Packet buffer memory
0.525 MB
Security
DHCP features
DHCP client
IGMP snooping
Y
Security algorithms
802.1x RADIUS
MAC address filtering
Y
Static port security
Y
SSH/SSL support
Y
Password protection
Y
Authentication type
RADIUS, TACACS+
Design
Rack mounting
Y
Stackable
Y
Form factor
1U
Product colour
Black
Reset button
Y
LED indicators
Y
Wall mountable
Y
Certification
EMC
¦ CE, FCC, C-Tick, Class A
(GS1900-24/24EP/24HPv2/48/
48HPv2)
¦ CE, FCC, C-Tick, Class B
(GS1900-8/8HP/10HP/16/24E)
¦ BSMI CNS13438
• Safety
¦ LVD EN60950-1
¦ BSMI CNS14336-1
¦ CB IEC60950-1
(GS1900-8HP/10HP/16/24E/24)
• RoHS compliant
Performance
Mean time between failures (MTBF)
804.714 h
Power
Power source
AC
Power supply included
Y
AC input voltage
100 - 240 V
AC input frequency
50/60 Hz
Power consumption (max)
15.1 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)
N
Operational conditions
Operating temperature (T-T)
0 - 50 °C
Storage temperature (T-T)
-40 - 70 °C
Operating relative humidity (H-H)
10 - 95%
Storage relative humidity (H-H)
10 - 95%
Heat dissipation
51.49 BTU/h
Weight & dimensions
Width
267 mm
Depth
162 mm
Height
42 mm
Weight
1.56 kg
Packaging data
Cables included
AC
Package type
Box
Rack mount kit
Y
Package width
325 mm
Package depth
223 mm
Package height
71 mm
Package weight
2.05 kg
Logistics data
Harmonized System (HS) code
85176990
