Introduction
Support 2.5 Gigabit High Network Speed
PoE12-30W is a Multi-Gigabit PoE injector supporting network speeds of up to 2.5Gbps. It is allowed to connect powered devices through existing Cat 5e or above cable.
High PoE Power
PoE12-30W complies with PoE+ providing PoE power budget up to 30 watts. It also offers interoperability and compatibility with other standard-based PoE devices.
Plug and Play—Ease of Use
PoE12-30W is easy to connect network devices without any configuration. The wall-mount and desktop design accommodate most installations scenarios.
Network
Ethernet interface type
2.5 Gigabit Ethernet
Ethernet LAN data rates
100,1000,2500 Mbit/s
Power over Ethernet (PoE)
Y
Networking standards
IEEE 802.3ab, IEEE 802.3at, IEEE 802.3bz, IEEE 802.3u
Features
Product colour
Black
Wall mountable
Y
Easy to install
Y
Plug and Play
Y
Mean time between failures (MTBF)
1869569 h
Ports & interfaces
Ethernet LAN (RJ-45) ports
2
RJ-45 input ports
1
RJ-45 output ports
1
Power
Input voltage
100 - 240 V
Input frequency
50/60 Hz
Input current
1 A
Total Power over Ethernet (PoE) budget
30 W
Operational conditions
Operating temperature (T-T)
-10 - 45 °C
Operating temperature (T-T)
14 - 113 °F
Operating relative humidity (H-H)
5 - 90%
Storage temperature (T-T)
-25 - 70 °C
Storage relative humidity (H-H)
5 - 90%
Weight & dimensions
Width
140 mm
Depth
45.5 mm
Height
30 mm
Weight
144 g
Packaging data
Package width
171 mm
Package depth
121 mm
Package height
42 mm
Package weight
918 g
Packaging content
Number of products included
1 pc(s)
Power cord included
Y
Information
| Part Number: | POE12-30W-GB0101F |
