Introduction
The most affordable choice for 10G migration
The XGS1930 series, a new 10G uplink smart managed switch, comes with a stylish new look and enables cloud manageability with Zyxel NebulaFlexTM technology.
Built for convenience
This smart-looking switch features an intuitive design that simplifies daily network management for SMBs.
Manage it your way!
The XGS1930 series introduces Zyxel NebulaFlexTM, which allows you to easily switch between standalone mode and our license-free Nebula cloud management platform anytime with just a few simple clicks.
Don’t overspend to upgrade your wired network
With Gigabit connectivity plus four 10G uplinks, the XGS1930 series is ideal for those seeking to upgrade to an easier-to-manage network—and at an affordable price.
Management features
Switch type
Managed
Switch layer
L2+/L3
Quality of Service (QoS) support
Yes
Web-based management
Yes
Cloud-managed
Yes
Traffic classification
Yes
Traffic shaping
Yes
ARP inspection
Yes
Configuring Location Settings (CLI)
Yes
System event log
Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity
24
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
SFP+ module slots quantity
4
Network
Networking standards
IEEE 802.1D, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support
Yes
VLAN support
Yes
Data transmission
Switching capacity
128 Gbit/s
Forwarding rate
95.2 Mpps
MAC address table
16000 entries
Jumbo frames support
Yes
Jumbo frames
9000
Packet buffer memory
1.5 MB
Security
DHCP features
DHCP client, DHCP relay
IGMP snooping
Yes
Multicast features
Design
Rack mounting
Yes
Stackable
Yes
Form factor
1U
Product colour
Black
LED indicators
Yes
Performance
Memory type
RAM / Flash
Internal memory
512 MB
Flash memory
32 MB
Power
Power source
AC
Power supply included
Yes
AC input voltage
100 - 240 V
AC input frequency
50/60 Hz
Power consumption (typical)
11.5 W
Power consumption (max)
23.2 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)
No
Operational conditions
Operating temperature (T-T)
-20 - 50 °C
Storage temperature (T-T)
-40 - 70 °C
Operating relative humidity (H-H)
10 - 90%
Weight & dimensions
Width
440 mm
Depth
270 mm
Height
433 mm
Weight
3.1 kg
Packaging content
Cables included
AC
Rack mount kit
Yes
Packaging data
Package width
508 mm
Package depth
394 mm
Package height
90 mm
Package weight
4.58 kg
